Edwards (590) Signaling transformer. 120v ac primary, 10v, 5va secondary

The Edwards 590 transformer is a Class 2 signaling transformer. It steps 120 VAC primary down to 10 VAC secondary at 5 VA. The unit is a compact single-phase doorbell-and-chime transformer with built-in thermal overload protection.

This transformer powers low-voltage signaling circuits. As a result, it is widely used for doorbells, chimes, intercoms, and low-voltage relay circuits. The unit mounts through a standard 1/2-inch electrical-box knockout. Alternatively, it surface-mounts using the provided foot brackets.

Key Features — Edwards 590 Transformer

• Primary: 120 VAC, 50/60 Hz
• Secondary: 10 VAC, 5 VA continuous
• Class 2 signaling transformer per UL and CSA
• Non-regenerative thermal overload protection
• Mounts in standard 1/2-inch knockout
• Surface-mount foot brackets included
• Compact footprint: 2-1/4 in W x 2-5/16 in D x 2-1/8 in H

Typical Applications

The Edwards 590 transformer is a general-purpose low-voltage power source. For example, it powers residential doorbells, chimes, low-voltage signal lights, and small relay circuits. In addition, it is widely specified in commercial intercom and signaling installations. As a result, it is a common drop-in replacement when an existing 10 VAC transformer fails.

Important: This Is a Class 2 Signaling Transformer, Not a Fire-Alarm Power Supply

The Edwards 590 carries UL Class 2 and CSA listings. However, it is not UL 864 listed for fire-alarm control or notification power. Therefore, do not use it as a primary or auxiliary power supply on a fire-alarm system. As a result, the 590 is best left to doorbell, chime, and general low-voltage signaling work.

Order the Edwards 590 Transformer

Life Safety Consultants stocks the Edwards 590 Class 2 signaling transformer. To confirm the voltage and VA match for your install, call 1-888-557-0558. Alternatively, email sales@lifesafetycom.com.
