The notifier dr-d4r door assembly is a D-size door for a Notifier CAB-4 series cabinet. Specifically, it is the window-style, four-tier door in red. The door accepts four chassis. In addition, it ships with a lock, two keys, and the hardware needed for the SBB-D4R backbox.
Notifier DR-D4R door assembly fit and intended cabinet
First, the door fits a four-chassis D-size CAB-4 backbox. Then, the integrated window gives a direct view of the panel display and trouble LEDs. As a result, the cabinet reads at-a-glance without unlocking.
In addition, the installer hinges the door on the right or left side in the field. Therefore, the cabinet adapts to either side of the mounting wall. Furthermore, the door opens a full 180° for clear service access.
Key specifications
- Manufacturer: NOTIFIER (Honeywell)
- Product type: CAB-4 series locking door, window
- Size: D-size, four tiers (accepts 4 chassis)
- Color: Red
- Material: 16-gauge steel
- Window: Built-in
- Hinge: Pin-type, right or left-hand selectable in the field; opens 180°
- Hardware: Lock, two keys, and door-to-backbox mounting hardware included
- Mating backbox: SBB-D4R (ordered separately)
- Weight: ~23.95 lbs
Compatibility notes
- Pair with an SBB-D4R backbox for a complete cabinet assembly.
- Window variant — choose the solid-door variant if no window is required.
- Available black variant: DR-D4 (four-chassis window door in black).
Order the Notifier DR-D4R door assembly from Life Safety Consultants
In addition to the DR-D4R, Life Safety Consultants stocks the SBB-D4R backbox, matching CAB-4 dress plates, and chassis hardware. As a result, the full cabinet build ships from one supplier. Furthermore, our team can confirm color and tier count against your panel order.
For more information, contact the Life Safety Consultants team at (888) 557-0558, or email us at: sales@lifesafetycom.com
Additional information
| Weight | 24.65 lbs |
|---|---|
| Dimensions | 51 × 28 × 3 in |
| Condition | New |
| Manufacturers | Notifier |
| Part Type | Replacement Part |
