The Wheelock LSPSTR3 is a high-fidelity speaker strobe from the Eaton Exceder LED3 line. It pairs a wide-range audio speaker with an LED strobe. As a result, one square wall appliance handles both voice messaging and visual alerting.
This model has a red housing with white “FIRE” lettering. The speaker accepts 25 V or 70 V audio circuits. Meanwhile, the strobe runs on 24 VDC over a two-wire connection.
Wheelock LSPSTR3 features
- LED strobe with field-selectable candela: 15, 30, 75, and 110 cd.
- High-fidelity speaker with a 300 to 8,000 Hz frequency response.
- 25 V and 70 V audio taps for distributed voice systems.
- Square wall housing in red with white FIRE marking.
- Two-wire 24 VDC strobe circuit.
Listings and applications
The speaker is listed under UL 1480, and the strobe is listed under UL 1971. In addition, the appliance carries ULC listings. Therefore, it fits emergency voice and alarm communication systems in commercial buildings.
Furthermore, the wide frequency range improves voice intelligibility. Also, the LED light source keeps strobe current draw low.
Have questions before you order? Then call the Life Safety Consultants team at 1-888-557-0558. You can also email us at sales@lifesafetycom.com.
Additional information
| Weight | 1.8 lbs |
|---|---|
| Dimensions | 7 × 5 × 3.5 in |
| Condition | New |
| Manufacturers | Wheelock |
| Part Type | Replacement Part |
