The Power Sonic PS-6580 F2 is a 6V, 58 Ah sealed lead acid (SLA / VRLA) battery. Specifically, it ships with F2 (0.250″ / 6.35 mm) quick-disconnect tabs. First, it provides high-capacity standby power for large fire alarm panels, emergency lighting inverters, and UPS systems. Then, the AGM construction is non-spillable and maintenance-free.
How the Power Sonic PS-6580 F2 is used
Therefore, integrators specify the PS-6580 for a 6V/58Ah SLA. Also, two in series make a 12V/58Ah loadout. Also, F2 quick-disconnect tabs handle higher current than F1. In addition, the AGM design lets the battery run in any orientation. As a result, the PS-6580 F2 covers larger standby loads that exceed what a single 12V/18Ah or 12V/35Ah battery delivers.
PS-6580 F2 product details
- Nominal voltage: 6.0 V (3 cells)
- Nominal capacity: 58.0 Ah at 20-hr rate (56.0 Ah at 10-hr)
- Terminals: F2 quick-disconnect tab (0.250″ / 6.35 mm)
- Chemistry: AGM sealed lead acid (VRLA), maintenance-free
- Case: ABS
- Dimensions: 7.28 in (L) × 4.41 in (W) × 8.07 in (H) (185 × 112 × 205 mm)
- Approximate weight: 19.5 lb (8.8 kg)
- Operating temperature: charge -4°F to 104°F (-20°C to 40°C); discharge 5°F to 122°F (-15°C to 50°C)
- Approvals: UL Recognized, UN2800 non-spillable; consult Power-Sonic for current detail
Typical applications
Specifically, common uses include large fire panel backup, emergency lighting inverters, big UPS systems, and standalone DC standby. Finally, confirm Ah and physical fit against the current Power-Sonic PS-6580 datasheet before ordering.
For more information, contact the Life Safety Consultants team at (888) 557-0558, or email us at: sales@lifesafetycom.com
Additional information
| Weight | 20 lbs |
|---|---|
| Dimensions | 7.28 × 4.41 × 8.07 in |
| Condition | New |
| Manufacturers | Life Safety |
| Part Type | Replacement Part |
