Simplex (4090-9051) Individual Addressable Module (IAM) 0618113


SKU: 4090-9051

IDNet and MapNet II communicating device

Simplex 0618113 Individual Addressable Module #4090-9051

The Simplex 4090-9051 Individual addressable modules (IAMs) receive both power and communications from a two-wire MAPNET II or IDNet circuit.  They provide location specific addressability to a single initiating device (such as single station smoke detector alarm contacts or heat detector contacts) or multiple devices at the same location by monitoring normally open dry contacts and the wiring to an end-of-line resistor.  With the Simplex Individual Addressable Module 4090-9051, you will be able to supply data and power due to its use of IDNET and MAPNET II technology.  The Simplex 4090-9051 is an encapsulated package with wire leads.  It does not provide a status indicating LED.  This device is compatible with 4008, 4010, 4010ES, 4100U, and 4100ES series control panels.

For more information about this IAM, contact the Life Safety Consultants team at (888) 557-0558 or email us at:



Additional information

Weight 0.25 lbs
Dimensions 2 × 2 × 5 in


Part Type

Individual Addressable Module (IAM)
