Resideo (943WG-WH) Mini Surface-Mount Magnetic Contact
The Resideo (943WG-WH) is a miniature wired magnetic contact in white. First mount the reed body on the door or window frame. Then mount the matching magnet on the moving panel.
The 943WG-WH is a wired intrusion contact for burglary alarm zones. It is not a fire-alarm initiating device.
Verified Specifications
- Switch type: Form A (SPST) reed
- Contact rating: 300 mA @ 30 VDC
- Magnet gap: 1 in (25 mm) maximum
- Leads: two 12 in (30 cm) wires
- Mounting: self-adhesive strip or screws
- Color: white
How the Resideo (943WG-WH) Installs
The body is mini-sized to fit thin door and window frames. As a result, it disappears against trim or sash. Also, multiple 943WG contacts can wire in series across one panel zone.
For a replacement magnet only, order the 943WG-WH-M. Furthermore, the matching brown variant of the full kit is the 943WG-BR.
Order or Get Application Help
Since 2002, Life Safety Consultants has stocked Honeywell and Resideo wired contacts. To order the 943WG-WH or check zone wiring, call 1-888-557-0558. You can also email sales@lifesafetycom.com.
For more information, contact the Life Safety Consultants team at (888) 557-0558, or email us at: sales@lifesafetycom.com
Additional information
| Weight | 0.5 lbs |
|---|---|
| Dimensions | 1 × 1 × 1 in |
| Condition | New |
| Manufacturers | STI |
| Part Type | Replacement Part |
