The Edwards FW-HSSX1 FireWorks to VESDA High Level Interface represents a critical integration point for advanced fire detection and monitoring systems in complex commercial environments. This precision-engineered interface module enables seamless communication between FireWorks addressable fire alarm panels and VESDA aspiration smoke detection systems, creating a comprehensive early warning network for sophisticated facility protection strategies.
Designed for professional fire alarm installers and facilities managers, the FW-HSSX1 provides robust bi-directional communication capabilities that allow VESDA early warning smoke detection data to be fully interpreted and integrated into primary fire alarm control systems. By bridging these advanced detection technologies, the interface supports multilayered smoke detection strategies critical in high-risk environments like data centers, industrial facilities, healthcare complexes, and mission-critical infrastructure.
The interface module utilizes advanced signal processing algorithms to translate VESDA detection levels into standard fire alarm panel inputs, ensuring comprehensive monitoring and rapid response protocols across diverse system architectures.
Key Features
- Fully compatible with Edwards FireWorks addressable fire alarm panels and VESDA aspiration detection systems
- Supports multiple detection sensitivity levels for granular smoke monitoring and reduced nuisance alarm potential
- UL 864 listed for comprehensive fire alarm control unit integration
- Configurable input/output mapping for flexible system design
- Compact design minimizes panel space requirements and simplifies installation
- Meets NFPA 72 requirements for fire alarm system interconnectivity
Specifications
- Operating Voltage: 24VDC nominal
- Current Draw: 50mA maximum
- Operating Temperature Range: 32°F to 120°F (0°C to 49°C)
- Relative Humidity: 10% to 93% non-condensing
- Dimensions: 5.5″ x 3.25″ x 1.25″ (approx.)
Recommended installation contexts include commercial office buildings, healthcare facilities, industrial manufacturing spaces, data centers, telecommunications infrastructure, and any environment requiring advanced, multilayered smoke detection and early warning capabilities.
For more information, contact the Life Safety Consultants team at (888) 557-0558, or email us at: sales@lifesafetycom.com
Additional information
| Weight | 6 lbs |
|---|---|
| Dimensions | 13.5 × 10.5 × 5.5 in |
| Condition | New |
| Manufacturers | Edwards |
| Part Type | Interface Module |
