The System Sensor SPCRL is a red L-Series ceiling speaker. It provides high-fidelity audio for indoor fire alarm and voice systems. As a result, occupants hear clear tones and voice messages during an emergency.
Rotary switches set both the power tap and the voltage. Therefore, installers tune output on site without swapping devices. In addition, the L-Series design keeps installation fast and clean.
System Sensor SPCRL Audio Output
The speaker offers 1/4, 1/2, 1, and 2-watt taps. Also, it runs at 25 or 70.7 V nominal. Then the 400 to 4,000 Hz range supports intelligible speech.
The SPCRL mounts to the ceiling for wide coverage. Furthermore, the red housing marks it as fire equipment. The compact round profile suits most commercial interiors.
Specifications
- Type: indoor ceiling speaker (speaker only)
- Color: red
- Power taps: 1/4, 1/2, 1, and 2 watts (field-selectable)
- Voltage: 25 or 70.7 V (field-selectable)
- Frequency range: 400 to 4,000 Hz
- Dimensions: 6.8″ dia. x 2.6″ D (173 x 66 mm)
- Wiring: 12–18 AWG
- Maximum humidity: 10 to 93% non-condensing
- Listing: UL 1480 (fire alarm speaker)
For more information, contact the Life Safety Consultants team at (888) 557-0558, or email us at: sales@lifesafetycom.com
Additional information
| Weight | 1.5 lbs |
|---|---|
| Dimensions | 7.5 × 7 × 4 in |
| Condition | New |
| Manufacturers | System Sensor |
| Part Type | Speaker |
