Resideo (943WG-WH-M) Mini surface contact, magnet

Resideo 943WG-WH-M Replacement Magnet

The Resideo 943WG-WH-M is the matching white magnet for the 943WG-WH mini surface-mount contact. It contains no electronics. As a result, it ships as a passive magnet body that pairs one-to-one with the reed contact.

This part is sold for service work. For example, replace it when a magnet body is damaged or lost during a door repair.

Verified Specifications

• Function: replacement magnet only (no reed, no leads)
• Pairs with: Resideo 943WG-WH mini surface-mount contact
• Maximum gap to contact: 1 in (25 mm)
• Mounting: self-adhesive strip or screws (included)
• Color: white

Installation Notes

Mount the magnet on the moving door or window leaf. Then close the door and verify the gap does not exceed 1 in. However, an open-circuit alarm at rest usually means the magnet sits too far from the reed.

For a full kit (reed + magnet + leads), order the 943WG-WH instead. In addition, the matching brown reed kit is the 943WG-BR.
