The Edwards 105DHISTR-FJ is a high-intensity xenon strobe beacon. It delivers a bright visual signal in demanding industrial locations.
This model carries a red lens and runs on 20 to 30 VDC. As a result, it fits a wide range of low-voltage signaling circuits. In addition, it is rated for Division 2 hazardous (adverse) locations.
Edwards 105DHISTR-FJ Construction
A xenon lamp produces the high-intensity flash. Specifically, the strobe flashes at about 65 flashes per minute. The lamp averages roughly 3000 hours of service life.
The housing meets NEMA Type 4X for corrosion resistance. Therefore it suits both indoor and outdoor use. The gray base uses glass-reinforced thermoplastic polyester resin with brass hardware. Also, a shatter-resistant polycarbonate double-fresnel lens spreads the light.
Specifications
- Type: high-intensity xenon strobe beacon
- Voltage: 20 to 30 VDC
- Current: 1.08 to 0.83 A
- Lens: red, double-fresnel polycarbonate, 4-1/2 in diameter
- Flash rate: about 65 flashes per minute
- Lamp life: approximately 3000 hours (average)
- Enclosure: NEMA Type 4X, indoor/outdoor
- Rating: Division 2 hazardous locations
- Circuit: diode polarized
Order or Get Application Help
Life Safety Consultants stocks genuine replacement parts and offers application support. To order or get help, call 1-888-557-0558. You can also email sales@lifesafetycom.com.
For more information, contact the Life Safety Consultants team at (888) 557-0558, or email us at: sales@lifesafetycom.com
Additional information
| Weight | 2 lbs |
|---|---|
| Dimensions | 7 × 7 × 8 in |
| Condition | New |
| Manufacturers | Edwards |
| Part Type | Strobe |
