The Edwards 4-16ANNMT is the surface-mount wallbox for the 4-16ANN annunciator. It supports the EST4 eight-wide-by-two-high annunciator configuration, which holds 16 user interface spaces.
First, the 4-16ANNMT ships with everything needed for surface mounting. As a result, no additional trim is required to finish the install cleanly on the wall. In addition, the depth is kept to a minimum to reduce wall penetration.
For semi-flush mounting, use the 3-CAB7B black wallbox instead. Specifically, the 4-16ANNMT is a surface-mount-only enclosure, per Edwards EST4 Remote Annunciators Data Sheet E85014-0003.
Key Features
- Surface-mount wallbox for the 4-16ANN, 16-space (8 wide × 2 high) EST4 remote annunciator
- Constructed from 14-gauge rolled steel with a black baked enamel finish
- Knockouts for 3/4-inch conduit
- Lag and keyway mounting holes for faster install
- Accepts the 4-CAB16D (metallic bronze) or 4-CAB16DR (red) front door assembly
- Listed under the EST4 system’s UL 864 and ULC-S527 approvals
Verified Specifications
- Annunciator capacity: 16 user interface spaces (8 wide × 2 high)
- Mounting style: surface mount only
- Material: 14-gauge rolled steel, black baked enamel finish
- Shipping weight: 27 lb (12.25 kg)
- Semi-flush alternative: order 3-CAB7B wallbox
Order or Get Application Help
To order the Edwards 4-16ANNMT, call 1-888-557-0558. You can also email sales@lifesafetycom.com.
For more information, contact the Life Safety Consultants team at (888) 557-0558, or email us at: sales@lifesafetycom.com
Additional information
| Weight | 27 lbs |
|---|---|
| Dimensions | 29 × 27 × 5 in |
| Condition | New |
| Manufacturers | Edwards |
| Part Type | Annunciator |
