The Fenwal 76-330002-101 Addressable Double Action Pull Station represents advanced fire alarm activation technology designed for professional fire protection systems. This intelligent, two-stage activation device provides enhanced security and reduces false alarm incidents by requiring a deliberate, two-step activation process for emergency signaling.
Engineered for commercial and institutional environments, this addressable pull station integrates seamlessly with modern fire alarm control panels in complex networked systems. Its robust design supports addressable communication protocols, enabling precise location identification and rapid emergency response in large facilities such as office complexes, educational institutions, healthcare facilities, and industrial environments.
Constructed with professional-grade materials and sophisticated electronic components, the Fenwal double action pull station delivers reliable performance in challenging environmental conditions while maintaining compliance with critical life safety standards.
Key Features
- Advanced two-stage activation mechanism prevents accidental alarm triggering
- Full addressability for precise location reporting in networked fire alarm systems
- Compatible with standard 24VDC fire alarm control panel configurations
- Tamper-resistant design with vandal-resistant transparent cover
- Simple retrofit and installation with standard electrical backbox mounting
- Indoor and outdoor rated enclosure with superior environmental resistance
Specifications
- Operating Voltage: 24VDC nominal
- Standby Current: < 350 µA
- Alarm Current: 20-25 mA
- Operating Temperature: 32°F to 120°F (0°C to 49°C)
Compliance and Certification
The Fenwal 76-330002-101 pull station meets or exceeds the following industry standards:
- NFPA 72 – National Fire Alarm and Signaling Code
- UL 268 – Smoke Detectors for Fire Protective Signaling Systems
- UL 464 – Audible Signaling Devices
- ADA compliance for accessibility requirements
For more information, contact the Life Safety Consultants team at (888) 557-0558, or email us at: sales@lifesafetycom.com
Additional information
| Weight | 2 lbs |
|---|---|
| Dimensions | 3 × 4 × 3 in |
| Condition | New |
| Manufacturers | Fenwal |
| Part Type | Pull Station |
