The Potter RBVS Retrofit Ball Valve Switch is a precision-engineered monitoring solution designed for comprehensive fire protection systems in commercial and industrial environments. This innovative pull station device enables critical supervision of water flow control valves, providing immediate detection and signaling capabilities for fire protection system status changes.
Engineered specifically for retrofit applications, the RBVS seamlessly integrates with existing fire protection infrastructure, allowing facilities managers and fire alarm contractors to upgrade monitoring capabilities without complete system replacement. Its robust design ensures reliable performance in demanding mechanical spaces, including mechanical rooms, utility areas, and complex fire suppression system configurations.
Ideal for use with wet, dry, pre-action, and deluge sprinkler systems, the RBVS provides comprehensive valve position monitoring that meets stringent fire alarm system requirements and facilitates rapid emergency response protocols.
Key Features
- Compatible with 2-1/2″ to 10″ ball valves across multiple system configurations
- NFPA 72 compliant monitoring switch with robust mechanical design
- Field-adjustable mechanical travel for precise valve position sensing
- Corrosion-resistant construction with stainless steel components
- Simple direct mount installation with minimal system interruption
- UL and FM Global listed for critical fire protection applications
Specifications
- Switch Type: Single Pole Double Throw (SPDT)
- Contact Rating: 10 Amp @ 125/250 VAC
- Operating Temperature: 32°F to 150°F (0°C to 66°C)
- Environmental Rating: NEMA 4 weatherproof
- Electrical Ratings: Non-inductive, 0.25A @ 30 VDC
Certified for compliance with critical industry standards including NFPA 72, UL 268, and UL 464, the Potter RBVS represents a professional-grade solution for comprehensive fire alarm system monitoring. Recommended for use in commercial facilities, educational institutions, healthcare environments, and industrial complexes requiring reliable fire protection system supervision.
For more information, contact the Life Safety Consultants team at (888) 557-0558, or email us at: sales@lifesafetycom.com
Additional information
| Weight | 0.6 lbs |
|---|---|
| Dimensions | 7.75 × 7.5 × 3 in |
| Condition | New |
| Manufacturers | Potter |
| Part Type | Pull Station |
