Potter 3008030 SignaLink Wireless Repeater Model WR
Description
The Potter SignaLink™ Bridge is a fully supervised wireless bridge designed to be attached to any non-explosion-proof dry contact sprinkler monitoring devices. It removes the need to hard wire sprinkler devices to each other, and operates on a 2.4 GHz frequency. Devices are able to communicate with each other up to a maximum of 800’. All enclosures are weather and UV resistant polycarbonate.Each device incorporates an integrated antenna. The receiver is equipped with an SMA bulkhead to allow for remote mounting of an external antenna for flexibility of installation.
The WR repeater can be powered by one 3.6 volt D size Lithium Thionyl battery or by the auxiliary power of the fire panel or UL 864 or UL 1481 listed 24 VDC supply with battery backup. See ordering information on page 10 for optional power supply. Per UL 864, if the repeater is powered by batteries it must be dedicated to only one transmitter receiver pair. If the repeater is powered by a listed supply it can support multiple receiver pairs. The device includes a cover tamper, pry-off tamper switch, an LED to indicate when it is transmitting, and an LED to aid in resetting the battery meter, see fig 3. For mounting to a post, use the optional post mounting kit #0090221
For more information about this Potter device, contact the Life Safety Consultants team at (888) 557-0558, or email us at : sales@lifesafetycom.com
Additional information
| Weight | 2.13 lbs |
|---|---|
| Dimensions | 7 × 5 × 3 in |
