The Edwards 4-CAB8D is the service-replacement metallic bronze front door assembly for an EST4 8-space lobby enclosure. Specifically, it pairs a metallic bronze outer door with a black inner door, giving 8 user-interface spaces arranged 4 wide by 2 high.
First, this door fits the 3-CAB5B semi-flush wallbox. Alternatively, it fits the 4-8ANNMT surface-mount wallbox. In addition, the inner door supports the EST4 control display modules and acts as a deadfront. As a result, field wiring stays protected during system operation.
Therefore, the 4-CAB8D is the right service replacement when an existing 8-space metallic bronze door needs to be swapped without changing the enclosure or the modules behind it.
Key Features
- Service-replacement door for EST4 8-space lobby enclosures
- 8 user interface spaces (4 wide × 2 high)
- Metallic bronze outer door (Pantone PMS P 171-16 C, RAL 7022)
- Black inner door doubles as a deadfront
- 14-gauge rolled steel with baked enamel finish
- Doors may be hinged on the left or right side
- Listed to UL 864 and ULC-S527 as part of the EST4 cabinet system
Verified Specifications
- User-interface capacity: 8 spaces (4 wide × 2 high)
- Outer door color: metallic bronze baked enamel
- Inner door color: black
- Material: 14-gauge rolled steel
- Compatible backboxes: 3-CAB5B (surface or semi-flush) or 4-8ANNMT (surface only)
- Hinging: left or right
- Shipping weight: 23 lb (10.43 kg)
Companion Parts
For a red door instead of metallic bronze, order 4-CAB8DR. For the matching plastic frame assembly, order 4-4X2ANNFA. For a tamper switch on the 3-CAB5B, order 3-TAMP5.
Order or Get Application Help
To order the Edwards 4-CAB8D, call 1-888-557-0558. Alternatively, email sales@lifesafetycom.com.
For more information, contact the Life Safety Consultants team at (888) 557-0558, or email us at: sales@lifesafetycom.com
Additional information
| Weight | 27.7 lbs |
|---|---|
| Dimensions | 27 × 20 × 8 in |
| Condition | New |
| Manufacturers | Edwards |
| Part Type | Annunciator |
