The Edwards EDGE-CLA1 Class A Adapter Module is a critical component for advanced fire alarm communication infrastructure, designed to enhance circuit reliability and monitoring in complex commercial fire detection systems. This precision-engineered module enables Class A (Style 6 or 7) communication circuits, providing redundant signal paths and continuous system monitoring for high-reliability applications where uninterrupted fire detection performance is paramount.
Engineered specifically for addressable fire alarm panels and intelligent detection networks, the EDGE-CLA1 supports comprehensive circuit management in challenging commercial environments such as multi-story office complexes, healthcare facilities, educational campuses, and critical infrastructure installations. By implementing advanced circuit supervision techniques, this module ensures immediate fault detection and maintains comprehensive system integrity even during individual circuit interruptions.
Fire alarm professionals can leverage this adapter module to transform conventional circuit designs into fully supervised, fault-tolerant communication networks that meet the most stringent life safety requirements.
Key Features
- Compatible with Edwards EST fire alarm control panels and addressable communication systems
- Full NFPA 72 compliant Class A circuit supervision and monitoring
- Enhanced fault tolerance with automatic circuit path redundancy
- Low-impedance design minimizing signal transmission losses
- Compact form factor for streamlined panel integration
- Compatible with UL 864 and UL 268 listed fire alarm control equipment
Technical Specifications
- Operating Voltage: 24VDC nominal
- Maximum Standby Current: 100µA
- Maximum Alarm Current: 10mA
- Operating Temperature Range: 32°F to 120°F (0°C to 49°C)
- Relative Humidity: 93% non-condensing
- Dimensions: 5.5″ x 3.25″ x 1.5″ (approximate)
Recommended installation contexts include commercial office buildings, healthcare facilities, educational institutions, hospitality environments, and industrial complexes requiring comprehensive fire detection and notification infrastructure. The EDGE-CLA1 supports seamless integration with existing Edwards EST intelligent control panels and supports advanced network configuration strategies.
Professional fire alarm technicians will appreciate the module’s robust design, which facilitates rapid commissioning and provides comprehensive diagnostic capabilities through advanced circuit supervision mechanisms.
For more information, contact the Life Safety Consultants team at (888) 557-0558, or email us at: sales@lifesafetycom.com
Additional information
| Weight | 2 lbs |
|---|---|
| Dimensions | 3 × 4 × 3 in |
| Condition | New |
| Manufacturers | Edwards |
| Part Type | Module |
